New 2011 Scheme

Features of the Cylindrical Hopper from North American Railcar Corporation:

• Meticulously researched and designed

• 2 different running boards (11 or 17 supports) – etched brass

• Etched Brass Crossover Platforms (with individually applied supports)

• 5 different Ends (bracing variations)

• 2 Different Outlet Gates (Toggle Lock and Spiral Cog)

• Investment castings for capstans (end of gates)

• 2 Different Hand Brakes (conventional and “High Power” Ellcon-National

• 2 Different Reservoir Positions (low for truck mounted cylinders and high for body mounted cylinders)

• External brake Rod on cares with body mounted brakes cylinders (including levers)

• 3 Different styles of trough hatches (smooth, slash, “V”)

• Kadee # 58 semi-scale couplers
•  Coupler Cut Bars

• 2 Bolster/Jack Pad Styles (flat and sloped faces)

• North American Railcar High-Performance Low Friction Trucks Barber S-2 100 ton-ton trucks with semi-scale 36” wheels

There are 12 Canadian National assigned road Numbers available in this release, change quantity in cart to order more than a single car, road numbers are:

• 01  /  397476

• 02  /  397269

• 03  /  397174

• 04  /  397131

• 05  /  397091

• 06  /  397053

• 07  /  397021

• 08  /  397449

• 09  /  397233

• 10  /  397166

• 11  /  397145

• 12  /  397128


For a complete list of all the different versions and explanations of the differences on the Hawker Siddeley 4550 cu ft Cylindrical Hopper go to this link: Click Here

Some customers asked, do you see both Green Saskatchewan Hoppers togther with the exclimation mark and without the exclimation mark?

Well, here is the proof!

Photo Credit: Michael Berry. Heading west through Pointe-Claire At left is a CP eastbound

Photo Credit: Michael Berry. CN 874 pulling into a crew stop at Turcot West. Almost half of the train was composed of these colorful cars
