Atlas - HO Scale - GP40-2 - Gold Series LokSound & DCC - CSX Transportation (CSX) - #6455 - Blue, Yellow "YN3b" (SKU 150-10002592)

Available On: August 1, 2017

atlas-logo

    The GP40-2 was EMD’s follow-up to the very successful GP40 locomotive model. While many internal upgrades were introduced (such as the use of improved, modular Dash 2 electrical components), there were some external differences between the early production GP40-2 and late-production GP40.
    This included an engine water-level sight glass on the right side of the body (a feature common to all EMD Dash 2 models), a larger electrical cabinet air filter
box, a lengthened battery compartment on the left side, and a slightly modified cab.
     All GP40-2s featured a 16-cylinder EMD 645-series diesel engine which was rated at 3,000 horsepower. Early to mid-production phase 2 GP40-2s were built
from mid-1976 through late-1979. Several major spotting features of Phase 2 units include: an 88” low nose, corrugated radiator grilles and notched step wells.

Features:

    Golden-white LEDs
    Realistic die-cast underframe
    Five-pole skewed armature motor with dual flywheels for optimum performance at all speeds
    Directional lighting
    Factory-equipped with AccuMate® knuckle couplers
    Detailed cab interior with crew
    Separately-installed scale windshield wipers, metal grab irons and fine scale handrails
    Movable drop steps
    Walkway safety tread
    Coupler cut bars
    Multiple unit hoses and trainline hoses
    Snowplow

Additional features include:

    Etched metal radiator and dynamic brake fans (included where appropriate per road name).
    Dynamic Brake options: standard range, extended range or non-dynamic brake hatch used where appropriate per road name.
    3,600 gallon fuel tank.

Undecorated units information:

    Dynamic Brake Part: standard range and non-dynamic brake hatch
    Hood and frame bells included
    3,600 and 2,600 Gallon fuel tanks included
    Trucks: Blomberg Type-M only
    The handrails will NOT be attached to the frame and will be packed separately.

DCC Operation Features:

    Supports all DCC-programming modes
    Flexible mapping of function keys F0 to F28.
    A total of six DCC function outputs are available
    Follows all NMRA DCC standards and recommended practices.

Analog (DC) Operation Features:

    The LokSound Select Dual-Mode decoder allows your Atlas Gold Series locomotive to be used on DC as well as on DCC layouts.
    Please note that the Atlas Quantum Engineer will NOT operate an Atlas Gold Series locomotive equipped with a LokSound Select decoder on an analog

(DC) layout. However, the sound and lighting functions of the LokSound Select decoder in the Atlas Gold Series GP40-2 locomotive can be controlled by an
easy-to-use basic DCC system
    Also note that on a DC-powered layout, a DCC and sound equipped locomotive (such as the Atlas Gold Series GP40-2) CANNOT be consisted with another
locomotive that does not also have both DCC and sound. (This statement does NOT apply to DCC-equipped locomotives operating on a DCC layout.)


Sound Functionality Features:

    Over 20 sound effects are available, including engine start-up and shutdown, prime mover sounds through all eight notches, bell, air horn, air compressor,
dynamic brakes and more.
    There are 16 user-selectable horns, 2 user-selectable bells, and 2 user-selectable synchronized brake squeals.
    Manual and Automatic Notching modes with the ability to change modes ”on the fly” are provided for true realism.







$269.95 US
