Athearn - HO Scale - SD45T-2 Locomotives - DCC & Econami Sound - Southern Railway of BC (SRY) so) - #340 - Dark Blue, Black,, White Lettering (SKU 140-86839)

Available On: May 1, 2019

Athearn RTR logo

PROTOTYPE AND BACKGROUND INFO:

    The SD45T-2 is a 6-axle diesel-electric locomotive built by EMD for the Southern Pacific Railroad. Like the similar SD40T-2 it is nicknamed a “tunnel motor”. 247 were built from February 1972 to June 1975, including 84 for SP’s subsidiary Cotton Belt. From April 1986 to December 1989 about half were rebuilt and designated as SD45T-2R and 24 of the 126 rebuilds were built for Cotton Belt.

    The SD45T-2 is an SD45-2 with cooling system modifications. The intake for radiator cooling air was moved to the walkway level and the cooling fans themselves were under the radiator cores, instead of above. Tunnel motors were built to perform best in tunnels in mountainous areas in the western United States. The air intake grills at the lower rear of the locomotives’ long hoods were intended to bring cool and clean air into the radiator section. The larger area of the intakes would also provide a less restrictive airflow.

    This page is based on the copyrighted Wikipedia article “EMD SD45T-2” (https://en.wikipedia.org/wiki/EMD_SD45T-2); it is used under the Creative Commons Attribution-ShareAlike 3.0 Unported License (CC-BY-SA). You may redistribute it, verbatim or modified, providing that you comply with the terms of the CC-BY-SA.


Detailed Information
NEW FEATURES FOR ALL SD45T-2S IN THIS ANNOUNCEMENT:

    First time offering DCC+Sound Version, including new T-2 rear truck design for more visibly see through grilles
    All-new LED lighting
    First time pilot detail including rubber MU hoses for durability
    Photo-etched stainless steel windshield wipers

LOCOMOTIVE FEATURES:

    Fully assembled and ready-to-run
    Rubber trainline and MU hoses with silver ends, first time offered
    “Mushroom” nose vent on right side
    Separately applied wire grab irons
    Standard late Dash-2 4-window/L-window cab without louvers or roof seam per prototype
    See through cab windows
    Fixed cab side windows
    Welded ECAFB
    See-through dynamic brake fans
    See through radiator grilles with new rear truck gearbox speific for the tunnel motor
    Fine scale handrails
    Photoetch windshield wipers, first time offered
    Separately applied air tanks
    Speed recorder attached to appropriate axle per prototype (except undecorated)
    McHenry scale knuckle spring couplers
    Highly-detailed, injection molded body
    Painted and printed for realistic decoration
    LED Lighting, first time offered
    New tooling HTC truck sideframes
    All-wheel drive with precision gears for smooth and quiet operation
    All-wheel electrical pickup
    5-pole motor with flywheels and multi-link drivetrain for trouble-free operation
    Compatible with Genesis motor retrofit kit
    Window packaging for easy viewing
    Interior plastic blister safely holds the model for convenient storage
    DCC Ready 21-pin NEM Quick Plug™ technology
    Available also with factory installed Econami Sound by Soundtraxx, first time offered
    Nickel plated, blackened machined wheels
    Wheels with RP25 contours operate on all popular brands of track
    Replacement parts available including motor brushes
    Minimum radius: 18”
    Recommended radius: 22”

SOUND EQUIPPED MODELS ALSO FEATURE

    Onboard Econami Sound by SoundTraxx
    Sound units operate in both DC and DCC
    Full DCC functions available when operated in DCC mode
    Engine, horn, and bell sounds work in DC
    All functions NMRA compatible in DCC mode
    Excellent Slow speed control
    Effect lighting (if applicable) using F5 and/or F6
    Program a multiple unit (MU) lashup with lead unit only horn, bell, and lights
    Many functions can be altered via Configuration Value (CV) changes

MRL/SRY FEATURES:

    Fire-cracker antenna
    Large EMD style plow
    Small anticlimber
    Coupler cut levers with loops
    Frame mounted bell
    Illuminated ditchlights
    Rebuilt EMD style nose
    Cab mounted headlight
    Hood mounted Nathan air horn

When the Union Pacifc absorbed the Southern Pacific in 1996, a number of SD45T-2 diesels started parting ranks from the parent railroad. While the MRL or the SRY never owned the SD45T-2, there was a time where the railfan community was hopeful that these rag-tag units would find their way to the MRL. Former SP EMD 20-cyl diesels had made it to the MRL in the early 1990s, making this scenario plausible. In the summer of 2004 a group of NREX SD45T-2s were being stored in Livingston, MT. further fueling the hopes of railfans.

As some MRL power migrated to the SRY, it could’ve been possible that the SRY brought an ex MRL SD45T-2 diesel into British Columbia. While none of this happened in real, model railroading allows for bending the rules a bit and admiring what could have been.

PRIMED FOR GRIME MODELS FEATURE:

    Duplicated look and feel of “In Service”equipment; “Tattered and Torn” just like the real thing
    Faded base colors matched to the prototype
    Patches applied and shaped per road number matching each corresponding side to the prototype
    Perfect starting point for adding grime and rust







$209.98 US
