Revolutionize freight service with WalthersMainline SD60 diesels. Based on mid-production EMD units built with safety cabs fitted with a three-piece windshield and designated as SD60M for modified, these heavy-haulers are still going strong for many original owners and shortlines.

Ready for service on your railroad, check out the many features including:

• Limited edition - one time run of these roadnumbers!

• Prototypes in service 1989 to the present in main line and regional service

• Mid-production safety cab with three-piece windshield

• Open grating on steps

• Available with ESU Sound & DCC for DCC & DC layouts featuring:
  • 4 Function outputs with brightness control by CV
  • Fully DCC Compatible
  • 14, 28, 128 Speedsteps
  • Dual Mode DC/DCC
  • 4 Air Horns changeable by CVs
  • 2 Bells Changeable by CVs
  • Full 8 Notch Prime Mover Sounds
  • Compressor
  • Dynamic Brake
  • Multiple realistic lighting effects
  • 21-pin DCC plug
• Same powerful drive as WalthersProto locos featuring:
  • 5-pole skew-wound motor
  • 14:1 gear ratio
  • Helical-cut gears for quiet operation and easy multiple unit operation
  • All-wheel drive and electrical pickup
  • Dual machined brass flywheels

• Heavy die-cast metal chassis

• Constant & directional LED headlights

• Updated shell with molded drill starter points for grab irons in EMD SD60M Diesel Detail Kit (#910-257) sold separately

• RP-25 metal wheels

• Proto MAX metal knuckle couplers


PLEASE NOTE: When operating Walthers-branded DCC-equipped locomotives in DC mode, do not use power packs that exceed an 18V rating. This includes MRC 1300-series power packs which have known issues with our decoders.

Make your WalthersMainline SD60M 2- or 3-Window models more realistic with these accessories, available separately:

SD60M Detail Kit
Walthers Double Ended Pin Vise
Walthers Drill Bits


Alternate Horns and Bells include: Horns: CV163 = Nathan K3LA (default) CV163 = Nathan P3 CV163 = Leslie RS3L CV163 = Nathan K5LA CV163 = Nathan P5

Bells: CV164 = Steel Air Bell (default) CV164 = Graham White E-Bell

Click here for additional information on DCC functions:

ESU CV List
ESU Function Mapping
ESU Function Output
